HBPS Energy Storage Converter 15~60kW
HBPS energy storage converter 15~60kW. 3-phase, HV 200-850V, >97% efficiency, multi-unit parallel, fast on/off grid switching.
Reference price: $3,309.00Pre-order
Stock: confirmed by orderFor households, installers, dealers, hotels, villas, and factories.
Battery, inverter, PV panel, and accessory availability is confirmed within 24h by city, quantity, and project configuration.
वॉरंटी 5 years
जगभर शिपिंग
100% मूळ
प्रमुख वैशिष्ट्ये
- Conversion efficiency >97%
- High voltage battery 200-850V, compatible with 280/314Ah cells
- 3-phase 400V, multi-unit parallel support
- Fast on/off grid switching <15ms
- Diesel generator hybrid operation support
- Suitable for villas, factories, islands, and farms
तांत्रिक तपशील
| 15kW | 25kW | 30kW | 40kW | 50kW | 60kW | |
|---|---|---|---|---|---|---|
| रेटेड पॉवर | 15kW / 15kVA | 25kW / 25kVA | 30kW / 30kVA | 40kW / 40kVA | 50kW / 50kVA | 60kW / 60kVA |
| जास्तीत जास्त बॅटरी करंट | 85A | 80A | 100A | 120A | 150A | 180A |
| जास्तीत जास्त AC करंट | 22A | 36A | 43.5A | 57.7A | 72.1A | 87A |
| ऑफ-ग्रिड पॉवर | 15kVA | 27.5kVA | 30kVA | 40kVA | 50kVA | 60kVA |
| PV इनपुट | - | - | - | 2 MPPT, max 40kW | 2 MPPT, max 50kW | 2 MPPT, max 60kW |
| प्रकार | Energy Storage Converter (PCS) | Energy Storage Converter (PCS) | Energy Storage Converter (PCS) | Energy Storage Converter (PCS) | Energy Storage Converter (PCS) | Energy Storage Converter (PCS) |
| बॅटरी व्होल्टेज | HV 200~850VDC | HV 200~850VDC | HV 200~850VDC | HV 200~850VDC | HV 200~850VDC | HV 200~850VDC |
| ग्रिड AC | 400V/230V 3-phase, 50/60Hz | 400V/230V 3-phase, 50/60Hz | 400V/230V 3-phase, 50/60Hz | 400V/230V 3-phase, 50/60Hz | 400V/230V 3-phase, 50/60Hz | 400V/230V 3-phase, 50/60Hz |
| कार्यक्षमता | >97% | >97% | >97% | >97% | >97% | >97% |
| ट्रान्सफर वेळ | <15ms | <15ms | <15ms | <15ms | <15ms | <15ms |
| समांतर | Multi-unit parallel | Multi-unit parallel | Multi-unit parallel | Multi-unit parallel | Multi-unit parallel | Multi-unit parallel |
| संवाद | RS485, CAN | RS485, CAN | RS485, CAN | RS485, CAN | RS485, CAN | RS485, CAN |
| तापमान | -30~60°C | -30~60°C | -30~60°C | -30~60°C | -30~60°C | -30~60°C |
| कूलिंग | Forced air | Forced air | Forced air | Forced air | Forced air | Forced air |
| वॉरंटी | 5 years | 5 years | 5 years | 5 years | 5 years | 5 years |
सुसंगत बॅटऱ्या
WhatsApp द्वारे मोफत सल्ला
5 मिनिटांत प्रतिसाद
वारंवार विचारले जाणारे प्रश्न
HBPS Energy Storage Converter 15~60kW ची वॉरंटी काय आहे?▼
HBPS Energy Storage Converter 15~60kW मध्ये Batelithium कडून 5 years वॉरंटी समाविष्ट आहे. वॉरंटी कालावधीत आम्ही पूर्ण तांत्रिक सहाय्य प्रदान करतो.
तुम्ही आंतरराष्ट्रीय शिपिंग करता का?▼
Batelithium जगभर शिपिंग करते. मोठ्या ऑर्डरवर मोफत शिपिंग. कस्टम कोटसाठी आमच्या टीमशी संपर्क साधा.
